Volvo V70 Model Year 2009

Choose Model

Source: Volvo Car Corporation.

Launch
The Volvo V70, launched in 2007, is the third model in Volvo's successful V70 concept. The model strengthens Volvo's position in the premium estate segment. An expressive design - with a characteristic Scandinavian touch - has been combined with a highly flexible and versatile interior with excellent loading possibilities. In addition, a sporty appearance, as well as sporty driving characteristics completes the model - and the model's overall exclusive impression.

New features, Volvo V70, model year 2009 - brief summary

• Savile Grey Pearl exterior colour
• Caper Green Pearl exterior colour
• Modified front head restraints
• "Auto Closing" buttons with side ridges
• Modernised claret walnut wood inlay
• HomeLink system
• 2.5T 5-cyl Flexifuel engine
• Self Supporting Tyres
• Tyre Pressure Monitoring System
• Atla 16" aluminium wheel
• Cassini 17" aluminium wheel

Please note that some systems and functions are optional.

Design
Five-door estate car.

The Volvo V70 has somewhat of a "dual personality", meaning a harmonious balance between spacious, versatile loading functions and sporty characteristics. In addition, the car has been given a higher level of luxury, to reinforce its premium qualities. The "soft nose" front, including an egg-crate grille with chromed vertical bars, creates a sporty yet luxurious "face". The tailgate's upper section has a sportier forward-leaning stance. The tailgate overlaps the tail lamps, providing an even wider opening. The glass goes further down at the sides, enhancing rear view. The loading space is increased by 55 litres (compared with the previous V70 model). The interior, with a Scandinavian touch, is a perfect combination of design and function.

Exterior colours:

• Metallic Silver (426)
• Electric Silver Metallic (477)
• Seashell Metallic (484)
• Oyster Grey Pearl (472)
• Titanium Grey Pearl (455)
• Ice White (614)
• Glacier Blue Metallic (485)
• Willow Green Metallic (471)
• Passion Red Solid (612)
• Ruby Red Metallic (454)
• Barents Blue Metallic (466)
• Magic Blue Metallic (467)
• Solid Black (019)
• Black Sapphire Metallic (452)
• New colour: Savile Grey Pearl (492)
• New colour: Caper Green Pearl (493)

The rear seat integrated child seats are adjustable in two steps. The top-class comfort level is characterised by increased passenger space - distance from front to rear passengers is increased by 21 millimetres, rear legroom by 48 millimetres and knee clearance by 21 millimetres. Width at shoulder height - in the front seats - is 30 millimetres wider than before. The ventilated front seats with perforated leather (option) are equipped with fans, lowering the seat cushion temperature. This contributes to an even greater seating comfort - especially on hot summer days.

As of model year 2009, new front head restraints will be introduced due to legal demands. The new front head restraints have reduced width and 25 mm increased height. Buttons with the "Auto Closing" function now have side ridges in order to prevent window/sunroof buttons from being activated by mistake (e.g., by a child or a dog) - something that can easily happen.

A new modernised claret walnut wood inlay will be introduced as an option. The new inlay will give the interior a more elegant and dynamic design. A total of nine different surfaces will be offered.

The Volvo V70 offers a number of loading solutions. The rear seat is split into three parts - 40/20/40, providing two very comfortable rear seats with a convenient armrest in between. The luggage compartment has aluminium rails and movable anchorage points. The anchorage points can be tucked down into the rails when not in use. The built-in anchorage eyelets in the side panels keep luggage securely in place. In addition, the side panels can be equipped with multifunctional rails, making it possible to attach hooks, load-anchoring nets and cargo space dividers among other loading accessories. The power-operated tailgate (option) can be opened with a push on the remote control. This facilitates loading when the owner has his or her hands full.

Safety
The Volvo V70 comes with a number of safety solutions - aimed to help avoiding accidents as well as reducing the consequences of a collision. The height-adjustable integrated child booster cushion provides children of different sizes with a good view through the windows, while at the same time contributing to a high level of protection. The booster cushion, providing optimum seat belt geometry, is even more effective in combination with the specially adjusted force limiters.

The Inflatable Curtain has been extended by 60 mm. In combination with the booster cushion and a strong body side, it helps increasing the side impact protection - for children of different sizes. In addition, the side structure has been combined with two-chamber side impact airbags. The Volvo V70 features Volvo's patented front structure as well. The structure is divided into zones with different steel grades. All engines are mounted transversely, including the six-cylinders, and help reducing the risk of penetration into the passenger compartment.

Volvo's Whiplash Protection System provides a gentle damping motion and contact between the head and head restraint throughout the impact sequence. The front has energy-absorption properties, including a soft structure (in front of the bumper) that helps reducing the risk of leg injuries to pedestrians.

The reinforced, lower spoiler edge is moved forward and almost on level with the bumper. This solution helps distributing the contact area of a pedestrian's or a cyclist's leg, helping to further reduce the risk of injury. The raised bonnet's underside has a honeycomb structure which helps absorbing the energy and reducing the risk of injury.

Collision Warning with brake support and emergency brake lamps helps avoiding rear-end impacts or minimise the consequences of a collision.

Adaptive Cruise Control helps keeping a safe distance to vehicles ahead.

The model has a number of advanced and interacting braking functions, such as Hydraulic Brake Assist, Optimized Hydraulic Brakes and Fading Brake Support. Volvo's Personal Car Communicator, an advanced pocket-sized control centre for increased personal security, is available for the Volvo V70. The Personal Car Communicator provides information about the car's lock and alarm status if the owner is up to 100 metres away from the car. It's even possible to detect if there's someone in the car.

Laminated glass all around, including the tailgate and rear side windows, is an option. The storage system under the luggage compartment floor has a loading capacity of 46 litres (without a spare wheel). The storage space locks automatically when closing and locking the tailgate.

The Volvo V70 can be equipped with the HomeLink system. The system makes it possible to operate up to three remote controlled home devices (e.g., garage door, home alarm system, etc.) via a module integrated into the sun visor. HomeLink contributes to easy and safe access to your home.

Driveline and chassis
The Volvo V70 is either front-wheel driven or equipped with AWD - All Wheel Drive. And - for the first time ever - the V70 model is offered with two six-cylinder engines - a powerful turbo engine and a highly comfortable, normally aspirated engine. As in all modern Volvo cars, the in-line six-cylinder units are mounted transversely. These engines are extremely compact and perfectly integrated with the front structure. The 3,0 litre turbo engine (T6) features a turbocharger technique, taking in exhaust gases in two stages. This enables a more compact turbocharger that provides extremely swift response, fully comparable with a twin-turbocharger solution.

The model will also be available with a 2.5 l five-cylinder, light-pressure turbo engine. The turbocharger is integrated into the manifold, contributing to the engine's compact format. The turbocharger withstands high exhaust temperatures and contributes to an efficient combustion and low exhaust emissions. This engine has been further developed and is now available in a Flexifuel model, delivering the same performance. It is compatible with both manual and automatic gearboxes. The Flexifuel engine meets the European emission standard Euro 4.

The five-cylinder turbo diesel provides smooth and powerful driving. This powerful and modern diesel engine features a service-free particle filter, making it a highly eco-efficient engine. The diesel engine is available in two versions.

The 2.0-litre, four-cylinder Flexifuel engine (2.0F) runs on bioethanol or petrol. This is a renewable fuel, lowering fossil carbon dioxide up to 80 %. Petrol and bioethanol can be mixed in the fuel tank.

The engine programme for the Volvo V70 is as follows:

Petrol	Cylinders	Power, bhp	Torque, Nm
2.0	4	145	190
2.5T	5	200	300
3.2	6	238	320
T6	6	285	400

Diesel*	Cylinders	Power, bhp	Torque, Nm
2.0D	4	136	320
2.4D	5	163	340
D5	5	185	400

*All diesel engines have a turbo function.

Flexifuel	Cylinders	Power, bhp	Torque, Nm
2.0F	4	145	190
2.5T	5	200	300

The five- and six-cylinder engines can be combined with Geartronic - an automatic six-speed gearbox with a manual gear changing function. In combination with the T6 engine, the Geartronic gearbox has a Sport mode, providing slightly faster gear change.

The chassis has been further developed, in comparison with the previous V70 model. In addition, the Volvo V70 can be equipped with Volvo's advanced chassis system - Active chassis with Four-C.

The T6 model is equipped with AWD - All Wheel Drive, distributing power between the rear and front wheels. The speed-dependent power steering (option) can be completed with a three-step adjustment function, making it possible to adjust the servo assistance and optimize road feedback. The Power Parking Brake is applied automatically, simplifying starting on uphill gradients for example. The DSTC (Dynamic Stability and Traction Control) system helps reducing the risk of skidding.

The Volvo V70 can be equipped with Self Supporting Tyres. A Self Supporting Tyre is constructed with stiffer sidewalls in order to carry the intended weight even if a puncture occurs. It is possible to drive at a maximum of 80 km/h for 80 km (fully loaded car) with Self Supporting Tyres. Driveability with a punctured tyre is almost equivalent to an optimally inflated tyre.

The Volvo V70 can be equipped with the Tyre Pressure Monitoring System - a control system that warns of low pressure in the tyres. The system has a pressure sensor integrated into the inflation valve in each wheel. The sensors are activated by an accelerometer at speeds over approximately 40 km/h.

Two new aluminium wheels are available: Atla 16" and Cassini 17".

Environment and air quality
The Volvo V70 is built and produced with the ambition of minimising the environmental impact. The efficient engines - diesels, petrols and Flexifuel - contribute to reduce the emission levels.

Volvo's Interior Air Quality System reduces particles, pollen, gases and unpleasant odours in the passenger compartment. In addition, all textiles and leather are certified under ÖKO-TEX 100. This is an international standard, which ensures that fabrics and hides have been thoroughly tested to check for certain allergy-inducing substances and emissions.

The Clean Zone Interior Package provides an improved in-car climate. The system ventilates the passenger compartment automatically (in temperatures above 10 degrees Celsius).

A convenient menu system makes it possible for the driver to adjust different systems - such as climate and rear-view mirrors. This system helps increasing the driver's focus on the road and contributes to a high level of comfort.

---
